Encryption
Miabi encrypts sensitive data at rest using a per-workspace key model. Secrets are never stored in plain text and never written to logs.
Per-workspace keyring (DEK model)
Each workspace has its own keyring built around a data-encryption key (DEK):
- A workspace's secrets are encrypted with that workspace's DEK.
- The DEK itself is protected by a root key derived from
MIABI_ENCRYPTION_KEY. - Because every workspace has distinct keys, the blast radius of any single key is contained to one tenant.
This DEK-per-workspace design keeps tenants cryptographically separated, complementing the workspace_id isolation at the data layer.
What is encrypted
Miabi AES-encrypts every secret value at rest, including:
| Secret | Source |
|---|---|
| App environment variables marked secret | Application configuration |
| Database passwords | Provisioned databases |
| Custom TLS private keys | Uploaded certificates |
| S3 / object-storage keys | Backup & storage backends |
| SSO client secrets | SSO configuration |
Non-secret values remain readable; only data marked or known to be sensitive is encrypted.
MIABI_ENCRYPTION_KEY
The root encryption key is supplied via the MIABI_ENCRYPTION_KEY environment variable. Miabi uses it to wrap each workspace's DEK.
export MIABI_ENCRYPTION_KEY="<a-strong-random-key>"
Treat MIABI_ENCRYPTION_KEY as the master secret for the entire instance. Generate it from a strong random source, store it in a secret manager, and back it up securely. If you lose it, encrypted data cannot be decrypted. Never commit it to source control or print it in logs.
GOMA_CONFIG_ENCRYPTION_KEY
Separate and optional. When set, Miabi encrypts the sensitive parts of the config it hands to Goma Gateway — middleware rules and TLS material — and each gateway decrypts it with the same key before applying. Empty (the default) leaves that gateway config unencrypted.
Because encryption and decryption happen on opposite sides, the same value must be set on both Miabi and the Goma gateway. In the Docker Compose stack that means setting GOMA_CONFIG_ENCRYPTION_KEY in your .env — it is passed to both the miabi and gateway services. For the remote edge gateways Miabi provisions on managed nodes, Miabi injects the key automatically, so a mismatch can't happen there.
export GOMA_CONFIG_ENCRYPTION_KEY="<a-strong-random-key>"
This is independent of MIABI_ENCRYPTION_KEY (which protects secrets in Miabi's own database). If the key is lost or the two sides disagree, a gateway can't decrypt its config — Miabi re-renders it on the next gateway deploy once the keys match again.
Key rotation
Miabi supports rotating keys without downtime, both manually (on demand) and automatically (on a schedule). Rotation re-wraps the workspace DEKs under a new root key version; existing encrypted data is migrated to the new key transparently. Rotate after a suspected exposure or as routine hygiene.
Crypto-shred on delete
When a workspace is deleted, Miabi crypto-shreds its keys — the workspace's DEK is destroyed. Because the encrypted data can no longer be decrypted, deletion is effectively irreversible for that workspace's secrets, even if encrypted blobs linger in backups.
Crypto-shredding makes workspace deletion a strong privacy guarantee. Export anything you need before deleting a workspace.
Related
- API Tokens are stored as hashes, a one-way complement to encryption.
- Review encryption and key events in the Audit Log.
