Encryption
Miabi encrypts sensitive data at rest using a per-workspace key model. Secrets are never stored in plain text and never written to logs.
Per-workspace keyring (DEK model)
Each workspace has its own keyring built around a data-encryption key (DEK):
- A workspace's secrets are encrypted with that workspace's DEK.
- The DEK itself is protected by a root key derived from
MIABI_ENCRYPTION_KEY. - Because every workspace has distinct keys, the blast radius of any single key is contained to one tenant.
This DEK-per-workspace design keeps tenants cryptographically separated, complementing the workspace_id isolation at the data layer.
What is encrypted
Miabi AES-encrypts every secret value at rest, including:
| Secret | Source |
|---|---|
| App environment variables marked secret | Application configuration |
| Database passwords | Provisioned databases |
| Custom TLS private keys | Uploaded certificates |
| S3 / object-storage keys | Backup & storage backends |
| SSO client secrets | SSO configuration |
| Configuration files | Configs |
| Registry, Git repository and DNS provider credentials | Sources and networking |
| Webhook and notification channel secrets | Webhooks & notifications |
Non-secret values remain readable; only data marked or known to be sensitive is encrypted.
Database backups are a separate layer: they are encrypted with a workspace passphrase you set, not with the keyring, and recovery points are sealed with a rotatable per-point data key. See Encrypting database backups and the recovery kit.
MIABI_ENCRYPTION_KEY
The root encryption key is supplied via the MIABI_ENCRYPTION_KEY environment variable. Miabi uses it to wrap each workspace's DEK.
export MIABI_ENCRYPTION_KEY="<a-strong-random-key>"
Outside a dev environment Miabi refuses to start without MIABI_ENCRYPTION_KEY, since secrets would
otherwise be stored unencrypted. Admin → Platform → Platform Settings shows the current encryption
posture (per-workspace keys, auto-rotation, gateway config encryption) read-only.
Treat MIABI_ENCRYPTION_KEY as the master secret for the entire instance. Generate it from a strong random source, store it in a secret manager, and back it up securely. If you lose it, encrypted data cannot be decrypted. Never commit it to source control or print it in logs.
GOMA_CONFIG_ENCRYPTION_KEY
Separate from the master key. When set, Miabi encrypts the sensitive parts of the config it hands to Goma Gateway — middleware rules and TLS material — and each gateway decrypts it with the same key before applying. Empty leaves that gateway config unencrypted.
A fresh install generates one and turns this on. It is written to spec.secrets.gomaConfigEncryptionKey in the install manifest and handed to both the control plane and the gateway from that one value, so the two sides cannot disagree. An existing install is never switched on by an upgrade: a host may run a gateway you imported, which Miabi does not redeploy and so cannot hand the key to — its routes would fail to decrypt with no visible cause. If config encryption is on while such a gateway is registered, Miabi names those nodes in its logs at boot.
Unlike MIABI_ENCRYPTION_KEY, the config it protects is rendered from the database on every sync. Rotating or losing it costs a converge and a re-sync, not data. The two sit side by side in the manifest with very different consequences.
Because encryption and decryption happen on opposite sides, the same value must be set on both Miabi and the Goma gateway. In the Docker Compose stack that means setting GOMA_CONFIG_ENCRYPTION_KEY in your .env — it is passed to both the miabi and gateway services. For the remote edge gateways Miabi provisions on managed nodes, Miabi injects the key automatically, so a mismatch can't happen there.
export GOMA_CONFIG_ENCRYPTION_KEY="<a-strong-random-key>"
This is independent of MIABI_ENCRYPTION_KEY (which protects secrets in Miabi's own database). If the key is lost or the two sides disagree, a gateway can't decrypt its config — Miabi re-renders it on the next gateway deploy once the keys match again.
Key rotation
Rotation replaces a workspace's DEK: Miabi creates a new key version, makes it active for new writes,
and re-encrypts the workspace's existing secrets under it. Once every value has moved, the old versions are
deleted. If part of the re-encryption fails, the old versions are kept (inactive) so nothing becomes
unreadable. MIABI_ENCRYPTION_KEY itself is not rotated by this.
- Manually — a workspace owner or admin clicks Rotate keys under Workspace settings → Encryption. This also activates a new sealing key. A workspace's keys can be rotated at most once every 6 months, and only from a signed-in session.
- Automatically — set
MIABI_KEY_AUTO_ROTATE=true. A daily job rotates every workspace key older thanMIABI_KEY_ROTATE_MONTHS(default6). An automatic rotation counts toward the 6-month limit.
Platform admins no longer rotate workspace keys from the admin console: the workspace owns its keys. Rotate after a suspected exposure or as routine hygiene.
Crypto-shred on delete
When a workspace is deleted, Miabi crypto-shreds its keys — the workspace's DEK and its sealing keys are destroyed. Because the encrypted data can no longer be decrypted, deletion is effectively irreversible for that workspace's secrets, even if encrypted blobs linger in backups.
Crypto-shredding makes workspace deletion a strong privacy guarantee. Export anything you need before deleting a workspace.
Related
- API Tokens are stored as hashes, a one-way complement to encryption.
- Review encryption and key events in the Audit Log.
